Abstract

Pickering emulsions, stabilized by solid particles rather than traditional surfactants, have gained significant attention in the pharmaceutical field for their unique physicochemical properties and enhanced stability. These emulsions offer a biocompatible and environmentally friendly platform suitable for various drug delivery applications, including oral, topical, and parenteral routes. Their ability to encapsulate both hydrophilic and hydrophobic drugs, protect sensitive bioactive, and provide controlled and targeted release makes them highly versatile. Recent advancements in the design of biopolymer- and nanoparticle-stabilized Pickering emulsions have further expanded their potential for improving drug solubility, bioavailability, and therapeutic efficacy. This review highlights the current developments, mechanisms, and future prospects of Pickering emulsions in pharmaceutical formulations, underscoring their promise as a next-generation drug delivery system.

Keywords

Emulsion, Pickering emulsions, Ramsden emulsions, biphasic system, nanoparticle, solid surfactant

Introduction

A biphasic system is a system consisting of two immiscible phases commonly liquid-liquid or solid-liquid that are stabilized together to form a single dosage form. The different types of biphasic system include: Suspensions (solid in liquid), Emulsions (liquid in liquid), Gels with suspended particles, and Liposome-based systems (aqueous core in lipid bilayer). An emulsion is a biphasic liquid dosage form composed of two immiscible liquids in which an emulsifying agent aids in one liquid (the dispersed phase) dispersed as tiny droplets in another liquid (the continuous phase)1. Emulsions are primarily classified based on the nature of the dispersed and continuous phases. In oil in water emulsion, the oil droplets are dispersed in water. Water is the continuous phase. It is common for oral and injectable formulations. Common examples are milk, intravenous lipid emulsions. Water droplets are dispersed in oil phase in water in oil emulsion. Here oil is the continuous phase. Common in topical and external application like cold creams, ointments. Multiple Emulsions are complex systems in which one immiscible liquid is dispersed within another liquid, and each droplet of the dispersed phase contain another emulsion within it. They can be either water in oil in water or oil in water in oil systems. Used for controlled drug delivery or masking taste. Microemulsions are thermodynamically stable, transparent and isotropic systems. The Droplet size ranges from 10–100 nm. These microemulsions are stabilized using co-surfactants and surfactants. These systems have better drug solubilization and absorption.1

Pickering Emulsion

Pickering emulsion is a type of emulsion which is stabilized by solid particles instead of conventional surfactants or emulsifiers. These solid particles absorb at the oil-water interphase and thus creates a mechanical barrier that eventually prevents coalescence of droplets.2,3 The concept of pickering emulsion dates back over a century, and found its greatest application in the recent decades because it is sustainable and surfactant-free systems. In 1903, Walter Ramsden first observed the phenomenon of solid particles adsorbing at oil-water interphase, later he published a paper entitled “Separation of solids in the surface-layers of solutions and suspensions”. He observed that, certain solid particles can adsorb to liquid interphase and prevent coalescence of droplet, however, his work did not gain popularity at that time. In 1907, S.U. Pickering, a British chemist published a comprehensive study entitled “Emulsions” in the journal of chemical society. He contoured how fumed or precipitated solids stabilized emulsion without the use of any surfactants. This led to the naming of this emulsion as pickering emulsions, even though the concept was first described by Walter Ramsden. Sometimes these emulsions are a referred as Ramsden emulsion. For a long time, Pickering emulsions did not find any practical applications since traditional surfactants ruled food, cosmetics and pharmaceutical industries. Pickering emulsions gained renewed attention in the 21st century with the growing demand for eco-friendly, biocompatible and surfactant-free products as well as nanotechnology and green chemistry. Now it is widely applied in the field of pharmaceuticals, cosmetics, food and material science.4 In an ordinary emulsion, surfactants stabilize the oil and water phase by lowering the interfacial tension, but in case of pickering emulsion, the traditional surfactants are replaced by solid particles, which adsorb physically at the interface of droplets to stabilize it. Mechanism of stabilization of pickering emulsion can be particle adsorption, interfacial attachment, or barrier formation. In particle adsorption solid particles attach irreversibly to the oil-water interface the particles must have intermediate wettability i.e., it should be neither too hydrophobic nor too hydrophilic. In interfacial attachment, particles once attached, reduce interfacial energy and form a dense layer around the droplets, preventing their fusion or coalescence. In barrier formation, the solid particle layer prevents coalescence by providing steric hindrance and electrostatic repulsion. The emulsion is free from creaming, coalescence or Ostwald ripening due to strong particle network.3

Mechanism Of Stabilization by Solid Particles

Pickering emulsions are stabilized not by surfactants, but by solid particles that adsorb at the oil-water interface. The stabilization mechanisms are interfacial energy minimization and physical barrier formation. Amphiphilic particles adsorb at the oil-water interface, once adsorbed particles anchor irreversibly due to the high energy required for the detachment, which forms a dense protective layer around each droplet. The adsorbed particles form a three-dimensional network, that helps to prevent droplet merging. Solid particles lower the interfacial tension, though less than the traditional surfactants, which reduces the total free energy of the system, making droplet formation more thermodynamically stable. The layer of solid particles also acts as a mechanical barrier to prevent coalescence and Ostwald ripening. Due to the energy barrier, once particle gets adsorbed at the interface, it is not readily desorbed, this enables long term stability even with out the use of surfactants.3,5

        <a href="https://www.ijpsjournal.com/uploads/createUrl/createUrl-20250606215843-1.png" target="_blank">
            <img alt="Mechanism Of Stabilization by Solid Particles.png" height="150" src="https://www.ijpsjournal.com/uploads/createUrl/createUrl-20250606215843-1.png" width="150">
        </a>
Figure 1: Mechanism Of Stabilization by Solid Particles

Solid Particles Used in Pickering Emulsion

A wide variety of solid particles are employed in pharmaceutical Pickering emulsions, depending upon their desired application and route of administration. Solid particles applied in Pickering emulsions should be partially wetted by both oil and water phases, they have a contact angle between 15°-150°, to ensure better stabilization. These particles are classified broadly based on their origin and functionality. Organic, inorganic, polymeric and biodegradable particles are widely applied in Pickering emulsion.  Functionalized particles are created by attaching desired functional groups to improve its stability and wettability properties. Inorganic particles like silica nanoparticles, titanium dioxide, calcium carbonate etc. are used commonly owing to their high surface energy and tunable surface chemistry. For example, hydrophobically modified silica can be used for stabilizing W/O emulsions for topical delivery of drug, which offers both emulsion stability and skin compatibility. Polymeric particles such as PLGA, polycaprolactone etc. are utilized for sustained release formulations. Natural biopolymer-based particles such as chitosan, cellulose nanocrystals, starch-based particles, whey protein, zein etc. are widely utilized for their non-toxicity and biodegradability. These formulations are particularly suitable for oral and topical preparations.  Hybrid and functionalized particles like magnetic nanoparticles for targeted drug delivery, pH responsive particles for controlled delivery of drug in specific gastric environments. Generally, the choice of solid particles in Pickering emulsions are controlled by factors like biocompatibility, wettability, particle size, surface charge, drug compatibility, and intended use.6

Table 1: Types Of Particles Used in Pickering Emulsion

Particles

Pickering emulsion

Composition

Shape

Composition

Shape

Composition

Inorganic particles

Silica (SiO2) nanoparticles

Spherical

O/W or W/O

60µm

Rotor-stator homogenizer

Calcium carbonate (CaCO3)

Irregular/ spherical

O/W or W/O

1-10 µm

High-shear mixing, vortexing, sonication

Titanium dioxide (TiO2)

Spherical/ rod shaped

O/W

100nm- 2µm

Sonication, high-shear homogenization

Hydroxyapatite

Spherical

O/W

-

-

Laponite

Spherical

O/W

1-30nm

Vertexing/ shear mixing

Organic and polymeric particles

Polylactic co-glycolic acid

Spherical

O/W or W/O

125 µm

Solvent evaporation or nanoprecipitation

Poly methyl methacrylate (PMMA)

Spherical

O/W or W/O

100nm- 5µm

Emulsion polymerization

Biopolymer based particles

Chitosan nanoparticles

Irregular/ spherical

O/W

6.9 µm

Sonication

Whey protein nanoparticles

Irregular/ spherical

O/W

200nm- 2µm

Homogenization / sonication

Cellulose nanocrystals

Spherical

O/W

32.17-32.83µm

Ultrasonic pulverization (30%, 3 min)

Bacterial cellulose nanocrystals

Needle-like

O/W

4µm

Ultrasonic device

Starch nanocrystals

Rod-like/ platelet shaped

O/W

>49.8µm

High- speed stirring/ homogenization

Zein

Spherical/ irregular

O/W

200nm- 2µm

Homogenization / sonication

Hybrid and functionalized particles

Magnetic nanoparticles

Spherical

O/W or W/O

<200nm

Ultrasonication

Janus nanoparticles

Spherical

O/W or W/O or multiple

100nm- 5µm

-

Carbon nanotubes

Tubular

W/O

100nm- 10µm

Sonication

Parameters Influencing Stability of Pickering Emulsions

There are several factors that can affect the formation, type and stability of emulsion. Understanding and controlling these factors is very essential for designing pickering emulsions for specific applications. Particle wettability (Contact angle): It is a key determinant of emulsion type. A contact angle < 90° (more hydrophilic) stabilizes oil-in-water emulsions, whereas contact angle >90° (more hydrophobic) stabilizes water-in-oil emulsions. Particles with 90° contact angle can stabilize both types of emulsions as well as multiple emulsions. Particle size and shape: smaller particles with nano to micrometer size range pack more densely at the interphase of the emulsion. Rod-like or plate-like particles offer stronger stabilization due to interlocking effects. Uniform particle size enhances emulsion stability. Particle concentration: higher particle concentration increases droplet coverage, reduce droplet size and may increase the viscosity. A minimum particle concentration is required for stable droplet coverage. Oil/water phase ratio determines whether the system favors oil-in-water or water-in-oil emulsions, additionally it influences droplet size and emulsion viscosity. pH of aqueous phase affects surface charge and stability of biopolymer particles.

Ionic strength (salt concentration): salt can screen electrostatic repulsions, promoting droplet flocculation or coalescence. Some particles become less effective at high ionic strength. Temperature affects viscosity of oil and water, particle solubility or aggregation, and phase transitions in thermoresponsive particles.

Mixing and emulsification method: shear force effect droplet size of particles. High speed homogenisation helps to disperse droplets and particles uniformly.

Surface modification of particles:

functionalization tailors, e.g., silanisation of silica, coating with polymers helps to increase wettability, surface charge and interaction with oil or water.5

Preparation Of Pickering Emulsion

General Protocol for Preparing Pickering Emulsion

Materials required:

  • Oil phase (e.g., sunflower oil, medium chain triglycerides, or any oil suitable for application)
  • Aqueous phase (e.g., distilled water or buffer)
  • Solid stabilising particles (e.g., whey protein–cress seed nanoparticles, cellulose nanocrystals)

Prepare the stabilizer suspension: disperse the solid particles (e.g., nanoparticles) in the aqueous phase using sonication to ensure homogeneity. 0.1-2% w/v particles are used.

Dissolve Drug: if using a hydrophobic drug, dissolve it in the oil phase. For hydrophilic drugs, dissolve it in the aqueous phase. The pH is adjusted to improve the solubility or to stabilize the drug.

Pre-emulsification: add the oil phase slowly into the aqueous suspension under stirring (e.g., magnetic stirrer at 500–800 rpm). Oil-to-water ratios usually range from 10:90 to 50:50 depending on the formulation needs.

High-Energy Emulsification: use a high-shear homogenizer at 10,000–20,000 rpm for 1–5 minutes, or ultrasonication for 2–5 minutes (pulse mode to prevent overheating). This reduces droplet size and helps particles adsorb to the interface.

Stabilization: keep the emulsion at room temperature or refrigerate it (depending on stability) to allow the particles to stabilize at the interface.7,8

Table 2: Types of homogenization techniques used

Method

Tuning process on droplet size

advantages

limitations

Reference

High-pressure homogenization

Pressure, homogenization cycle

Rapid process, large volume of samples can be processed, tunable droplet size in nanometer range,

Higher cost, increased temperature, risk of particle disruption, lack of monodispersity regulation

9

Ultrasonic emulsification

Ultrasonic frequency, amplitude and time

Rapid process, easy to set up, small volumes of samples can be processed, tunable droplet size

increased temperature, risk of particle disruption, lack of monodispersity regulation

10

Membrane emulsification

Membrane pore size, pressure

Energy consumption is low, reduced risk of particle disruption, reduced risk of temperature rise, low polydispersity

More time consuming, low viscosity systems are only suited

11

Microfluidic emulsification

Flow rate, microchannel geometry

Low polydispersity, reduced risk of temperature rise, low energy consumption

Low productivity, low viscosity systems are suited

12

Characterization Techniques Used For Pickering Emulsion

Characterization techniques provide a comprehensive understanding of stability, performance and efficacy of Pickering emulsions in pharmaceutical formulations.

Droplet size and particle size distribution: dynamic light scattering or laser diffraction can be used to measure average droplet diameter as well as particle size distribution. This is an important factor that affects the drug release rate, stability as well as bioavailability. Smaller and uniform droplet favors stability.

Zeta potential: electrophoretic light scattering using a zeta sizer assesses the surface charge of emulsion droplets. High zeta potential suggests good stability due to repulsion among droplets.

Interfacial tension: pendent drop method using tensiometer or goniometer measure the tension between oil and water phases. The adsorption of particles at the interface reduces interfacial tension, indicating effective stabilization.

Rheology: rotational rheometer evaluates viscosity, shear thinning, thixotropy and viscoelastic properties. It is widely used to predict the injectability or spreadability of topical formulations.

Encapsulation efficiency: can be performed using centrifugation or dialysis followed by drug quantification using UV-Visible spectrophotometry or HPLC.

In-vitro drug release: measured using dialysis bag method, Franz diffusion cell or USP dissolution apparatus. Samples are withdrawn periodically followed by UV/Visible or HPLC analysis, which evaluated the release kinetics to understand controlled release behavior.13

Applications Of Pickering Emulsion

Table 3: Application of Pickering emulsion in various fields

Field

Application

Pharmaceutical

  • Controlled drug delivery (e.g., fluconazole, curcumin, metronidazole)
  • Vaccine adjuvants – topical creams with enhanced stability

Food

  • Fat replacement,
  • encapsulation of flavors or nutrients
  • prolonged shelf-life via oxidation resistance

Cosmetics

  • Creams and lotions with improved stability and mildness
  • Natural, mild formulations, free of synthetic surfactants

Environment

  • Oil spill remediation,
  • encapsulation of hazardous waste

Agrochemical

  • Controlled release of pesticides and fertilizers
  • Reduced environmental impact due to slow degradation

Applications Of Pickering Emulsion In Pharmaceuticals

Pickering emulsions serve as a robust platform in pharmaceutical formulations, demonstrating superior stability and reduced toxicity compared to surfactant-based systems. They are shown to be effective in controlled drug release, tissue targeting, and encapsulation.

Drug Delivery Systems

        <a href="https://www.ijpsjournal.com/uploads/createUrl/createUrl-20250606215843-0.png" target="_blank">
            <img alt="Drug Delivery Systems Using Multi-Level Loading.png" height="150" src="https://www.ijpsjournal.com/uploads/createUrl/createUrl-20250606215843-0.png" width="150">
        </a>
Figure 2: Drug Delivery Systems Using Multi-Level Loading14

Pickering emulsions can be produced by mounting the interfacial-aggregated particles on the oil droplet, allowing large amounts of hydrophobic components to be encapsulated within oil nuclei. Also, the particulate O/W interface presented high specific surface areas for the efficient adsorption of a variety of macromolecules, such as antibodies, antigens, or therapeutic proteins. Moreover, the compactly packed particles could be exploited with the hierarchical structure (hollow or porous particles), as well as the tunable surface properties. These unique features enabled key drug loading via the hydrophobic interactions, chemical linking, or electrostatic adsorptions on the surface. For example, through the use of cashew gum nanoparticle-stabilized droplets, hydrophobic indomethacin was encapsulated within the oil core, with the encapsulation efficiencies up to 52%. In addition, Han et al. achieved up to 94% curcumin encapsulation in the inner oil containing medium chain triglyceride by using a chitosan/gum arabic nanoparticle-stabilized oil-in-water Pickering emulsion. Moreover, with the multi-level structures, Pickering emulsion can be utilized as potent multi-drug delivery systems. Cocktail therapy, which involves the co-administration of multiple drugs (such as cancer vaccines along with photothermal therapy, and chemotherapeutics), has often been shown to be a promising treatment for tumor regression and for multi drug resistance. But the main challenge was to spatiotemporally deliver multiple drugs with varied hydrophobicity and target sites. For example, the near infrared dye indocyanine green, which was regularly used in photothermal therapy, was a hydrophobic active component, while most of the targeted antibodies were hydrophilic molecules. A simple mixture of the hydrophobic drugs and antibodies can hardly bring about potent anti-tumor effect. Thus, it is very essential to develop multi-drug delivery systems for higher bioavailability as well as efficacy. The multi-level structure of Pickering emulsion may create the way for the strategic loading of multiple components with varying hydrophobicities or charges, thereby maximizing the overall benefit. In a recent study by Zhang et al., co-encapsulated betanin and curcumin through a type of water-in-oil-in-water (W/O/W) Pickering emulsion were stabilized by sugar beet pectin-bovine serum albumin nanoparticles (SBNPs). First, betanin was loaded in the inner water phase (W1) and curcumin was loaded in the oil phase. Then, W1/O emulsions were stabilized by polyglycerol polyricinoleate in the oil phase, and SBNPs dispersed in the outer water phase were homogenized with W1/O emulsions to form the double emulsion. Here, betanin was encapsulated within the internal water phase (encapsulation efficiency was 65.3%), whereas curcumin was in the oil phase (encapsulation efficiency was 84.1%). Furthermore, betanin and curcumin achieved a synergistic effect by hindering the A549 cell growth.14

Oral Route of Drug Delivery

Table 4: Examples of oral delivery of Pickering emulsions

Type

Emulsion

Drug/localisation

Functional changes

Reference

Particles

Droplet Size

O/W

Eudragit RL100 nanoparticles

≈220nm

Ketoprofen/oil

Controlled release

15

O/W

Acetylated cellulose nanocrystals

1-5µm

Decane/oil

-

16

O/W

Zein nanoparticles coated with bioactive glycyrrhizic acid and tannic acid

-

Curcumin/oil

Gastrointestinal pH sensitive

17

O/W

Magnesium oxide nanoparticles

≈666nm

Caffeine/water

Sustained release

18

O/W

Chitosan hydrochloride/ carboxymethyl starch complex

≈5-8µm

Beta-carotene/oil

-

19

O/W

Silybin nanocrystals

≈24.2-30.4 µm

Silybin/nanoparticles

Self-stabilized Pickering emulsion

20

O/W

Pea protein isolate protein

≈3-8µm

Beta-carotene/oil

Stimulus responsive and targeted delivery

21

W/O

Kafirin nanoparticles

-

Curcumin/kafirin nanoparticles

Protection against photooxidation of curcumin

22

Topical Route of Drug Delivery

Table 5: Examples of topical delivery of Pickering emulsions

Type

Emulsion

Drug/localisation

Functional changes

Reference

Particles

Droplet Size

O/W

Silica particles

≈2-4µm

Retinol/ oil

Sustained release

23

W/O

Aluminium starch octenyl succinate particles

-

Minocycline hydrochloride/ water

Controlled release

24

W/O

Chitosan/ collagen peptide nanoparticles

≈7.63=-15.72µm

-

-

25

O/W

Carboxymethyl chitosan/ sodium alginate nanoprticles

≈5µm

Curcumin/ oil

Controlled release

26

W/O

Silica prticles

≈100-200nm

Caffeine

Enhanced permeation

27

O/W

Cyclodextrin

-

Econazole/ cyclodextrin oil nanoparticles

-

28

W/O

Starch

≈10-20µm

-

-

29

Parenteral Route of Drug Delivery

Table 6: Examples Of Parenteral Delivery of Pickering Emulsions

SC/IV

Type

Emulsion

Drug/localisation

Functional changes

Reference

Particles

Droplet Size

SC

O/W

PLGA-PEG-mannose nanoparticles

≈1µm

Lipopeptide ovalbumin/ oil water interface

Targeted delivery

30

O/W

Alum microgels

≈4µm

SARS-CoV2 spike protein/ oil water interface

Targeted delivery

31

IV

O/W

Poly (N-isopropylacrylamide-co-allylamine) nanogels

≈1.5µm

Paclitaxel/ oil

Sustained release/ Targeted delivery

32

O/W

CTAB and LA

≈294-502nm

CTAB & LA/ nanoparticle

Targeted delivery/ stimuli response

33

W/O

PLGA nanoparticles

-

Oxaliplatin/ water

Sustained release

34

O/W

Poly (N-isopropylacrylamide-co-acrylic acid)

≈1-10µm

-

Sustained release

35

O/W

Solid lipid nanoparticles

≈40-160nm

-

Temperature sensitive delivery

36

Vaccine Delivery

Pickering emulsions can be used for the administration of vaccines. It is now been expolerd as a potential adjuvent for vaccines.

Table 7: Examples of Pickering emulsions (PE) used for vaccine delivery

Pickering emulsion

Delivered substance

Advantages

Reference

Chinese yam polysaccharide PLGA stabilized PE ajuvant system

Porcine circovirus 2 vaccine

High antigen uptaake efficiency by macrophages

37

PE based nanovaccine using manganese particle mineralized human serum albumin (MnHSA) and antigen ovalbumin (OVA) as stabilizers

OVA/ MnHSA nanoemulsion

Increased antigen encapsulation efficiency

38

PE guided monophosphoryl lipid A monomeric delivery system

Monophosphoryl lipid A

Elicit robust cellular immune response, enhanced cancer immunotherapy

39

Lentinan PLGA stabilized PE loading ovalbumin antigen

Lentinan/ ovalbumin

Activation of dentritic cells, strong humoral and cellular immune response

40

Cancer Therapy

Table 8: Examples of Pickering emulsions used for cancer therapy

Pickering emulsion

Route of administration

Advantages

Reference

Ultrastable iodinated oil-based PE for local sustained co-delivery of HIF-1 inhibitor of acriflavine and doxorubicin

Intratumoral

Long term sustained release

41

Fe2O4 cellulose nanocrystal stabilized PE containing curcumin for colon cancer

-

Stimuli responsive drug release (magnetically triggered)

42

PE of anti-CLTA4 antibodies formulated with radioopaque ethiodized oil and PLGA nanoparticles

Intratumoral/ intra-arterial

Delivery of novel cancer immunotherapy agents

43

Pickering nanoemulsion with multi-sensitive nanogels with pH-responsive, hydrophilicity-hydrophobicity switch, and redox-responding properties as an oil/water interfacial stabilizer and doxorubicin and ICP inhibitor HY19991

-

Ph resposive delivery, enhanced tumor penetration of doxorubicin

44

Wound Healing

Pickering emulsions can also be utilized for wound healing application.

Table 9: Examples of Pickering emulsions used for wound healing

Pickering emulsion

Advantages

Reference

Pickering emulsion composed of chitosan nanoparticles, tea tree oil and curcumin

Sustained release of therapeutic agents, promote fibroblast proliferation

45

Rutin loaded novel Pickering emulsion stabilized by self-aggregated chitosan particles

Sustained release of therapeutic agent

46

Pickering emulsion composite hydrogels based on carboxymethyl chitosan - sodium alginate nanoparticles stabilized Pickering emulsions, poloxamer 407, and curcumin

protecting bioactive components and wound care management

47

Novel Pickering emulsion with thyme essential oil encapsulated in shell of functional tea polyphenol-curcumin nanoparticles

rapid angiogenesis, collagen deposition, and skin regeneration

48

Advantages Of Pickering Emulsion

Pickering emulsions have high stability as the particles do not desorb easily. When compared to conventional emulsions, these are stable against Ostwald ripening and coalescence. Biocompatibility can be obtained using food or pharma grade particles. Low toxicity is achieved especially when surfactants are not desirable. Most of the particles used for formulating Pickering emulsion are biodegradable in nature, therefore has environmental sustainability. Also, the surface properties of particles can be tailored for smart functions to improve customizability. Most importantly these particles are highly tunable based on the application, functionalization can be performed to meet the needs.2,4

Limitations

Even though Pickering emulsions offers various advantages like enhanced stability, reduced dependence on synthetic surfactants and tunable release properties, they also face some limitations that can influence their formulation, scalability as well as practical applications. The major limitation is limited particle availability, only some solid particles can be suited for preparing Pickering emulsions that meets the criteria of biodegradability, compatibility and non-toxicity. The surface modification of the particle is practically difficult, requires complex chemical modification, which is time consuming, costly and may induce safety concerns for human use. These particles are typically irreversible due to strong adsorption at the interface, which makes them difficult to re-emulsify, causing challenges like redispersion after drying. Because of their high viscosity in highly concentrated Pickering emulsion, it is difficult to formulate in injectable form and to apply as topical form. Poor distribution and strong interaction among particles can limit bioavailability and drug release. High energy emulsification is utilized for preparation which may not be practical and economical for industrial scale, which hinders it’s scale up. Also, achieving uniform particle size distribution and emulsion droplet size is challenging on a larger scale. The use of novel nanoparticles requires strict regulatory scrutiny, which obstructs its wide scale applications.3,5

Future Prospectives

Currently, there is no FDA-approved drug labelled as Pickering emulsion. Many stabilizing particles used in Pickering emulsions are labelled as GRAS (generally regarded as safe) or FDA-approved. Formulations using Pickering emulsions are under clinical trials or in the preclinical stage of development. In future more and more Pickering emulsions containing solid adsorbed particles could be developed with more stability and practical application.

CONCLUSION

In conclusion, Pickering emulsions' improved stability, biocompatibility, and capacity to encapsulate and protect active medicinal components have made them a potential platform in pharmaceutical applications. Their use of solid particles as stabilizers makes them a safer and more environmentally friendly substitute for conventional surfactants, which makes them suitable for topical formulations, controlled release applications, and drug delivery systems. Pickering emulsions' adjustable characteristics facilitate the development of novel treatment approaches by enabling the modification of drug release profiles, enhanced bioavailability, and targeted delivery. In order to fully utilize their potential in commercial pharmaceutical formulations, more research and optimization are required.

REFERENCES

  1. Kale SN, Deore SL. Emulsion Micro Emulsion and Nano Emulsion: A Review. Systematic Reviews in Pharmacy [Internet]. 2016 Nov 19;8(1):39–47. Available from: https://www.sysrevpharm.org/fulltext/196-1568993217.pdf
  2. Wu J, Ma GH. Recent Studies of Pickering Emulsions: Particles Make the Difference. Small. 2016 Jun 23;12(34):4633–48.
  3. de Carvalho-Guimarães FB, Correa KL, de Souza TP, Rodríguez Amado JR, Ribeiro-Costa RM, Silva-Júnior JOC. A Review of Pickering Emulsions: Perspectives and Applications. Pharmaceuticals [Internet]. 2022 Nov 1;15(11):1413. Available from: https://www.mdpi.com/1424-8247/15/11/1413
  4. Wypych F, Alves R. Clay Minerals and Synthetic Analogous as Emulsifiers of Pickering Emulsions. Elsevier; 2022.
  5. Chevalier Y, Bolzinger MA. Emulsions stabilized with solid nanoparticles: Pickering emulsions. Colloids and Surfaces A: Physicochemical and Engineering Aspects. 2013 Dec; 439:23–34.
  6. Yang Y, Fang Z, Chen X, Zhang W, Xie Y, Chen Y, et al. An Overview of Pickering Emulsions: Solid-Particle Materials, Classification, Morphology, and Applications. Frontiers in Pharmacology. 2017 May 23;8.
  7. Albert C, Beladjine M, Tsapis N, Fattal E, Agnely F, Huang N. Pickering emulsions: Preparation processes, key parameters governing their properties and potential for pharmaceutical applications. Journal of Controlled Release. 2019 Sep;309:302–32.
  8. Wu J, Ma GH. Recent Studies of Pickering Emulsions: Particles Make the Difference. Small. 2016 Jun 23;12(34):4633–48.
  9. Chutia H, Mahanta CL. Properties of starch nanoparticle obtained by ultrasonication and high pressure homogenization for developing carotenoids-enriched powder and Pickering nanoemulsion. Innovative Food Science & Emerging Technologies. 2021 Dec;74:102822.
  10. Silva EK, Costa ALR, Gomes A, Bargas MA, Cunha RL, Meireles MAA. Coupling of high-intensity ultrasound and mechanical stirring for producing food emulsions at low-energy densities. Ultrasonics Sonochemistry [Internet]. 2018 Oct 1 [cited 2023 Apr 2];47:114–21. Available from: https://www.sciencedirect.com/science/article/pii/S1350417718306424?via%3Dihub
  11. Sun G, Qi F, Wu J, Ma G, Ngai T. Preparation of Uniform Particle-Stabilized Emulsions Using SPG Membrane Emulsification. Langmuir. 2014 Jun 9;30(24):7052–6.
  12. Opalski AS, Kaminski TS, Garstecki P. Droplet Microfluidics as a Tool for the Generation of Granular Matters and Functional Emulsions. KONA Powder and Particle Journal. 2019 Jan 10;36(0):50–71.
  13. Low LE, Siva SP, Ho YK, Chan ES, Tey BT. Recent advances of characterization techniques for the formation, physical properties and stability of Pickering emulsion. Advances in Colloid and Interface Science. 2020 Mar;277:102117.
  14. Ming Y, Xia Y, Ma G. Aggregating particles on the O/W interface: Tuning Pickering emulsion for the enhanced drug delivery systems. Aggregate. 2022 Feb 1;3(2).
  15. Dieng SM, Omran Z, Anton N, et al. Pickering nano-emulsions stabilized by Eudragit RL100 nanoparticles as oral drug delivery system for poorly soluble drugs. Colloid Surf B-Biointerfaces. 2020;191:111010 4.
  16. Torlopov MA, Vaseneva IN, Mikhaylov VI, Martakov IS, Moskalev AA, Koval LA, et al. Pickering emulsions stabilized by partially acetylated cellulose nanocrystals for oral administration: oils effect and in vivo toxicity. Cellulose. 2021 Jan 27;28(4):2365–85.
  17. Li Z, Liu W, Sun C, Wei X, Liu S, Jiang Y. Gastrointestinal pH-Sensitive Pickering Emulsions Stabilized by Zein Nanoparticles Coated with Bioactive Glycyrrhizic Acid for Improving Oral Bioaccessibility of Curcumin. ACS Applied Materials & Interfaces. 2023 Mar 8;
  18. Heba Elmotasem, Farag HK, Salama A. In vitro and in vivo evaluation of an oral sustained release hepatoprotective caffeine loaded w/o Pickering emulsion formula – Containing wheat germ oil and stabilized by magnesium oxide nanoparticles. International Journal of Pharmaceutics. 2018 Aug 25;547(1-2):83–96.
  19. Li XM, Li XH, Wu ZZ, et al. Chitosan hydrochloride/carboxymethyl starch complex nanogels stabilized Pickering emulsions for oral delivery of β-carotene: protection effect and in vitro digestion study. Food Chem. 2020;315:126288. doi:10.1016/j.foodchem.2020.126288
  20. Yi T, Liu C, Zhang J, Wang F, Wang J, Zhang J. A new drug nanocrystal self-stabilized Pickering emulsion for oral delivery of silybin. European Journal of Pharmaceutical Sciences. 2017 Jan 1;96:420–7.
  21. Shao Y, Tang CH. Gel-like pea protein Pickering emulsions at pH 3.0 as a potential intestine-targeted and sustained-release delivery system for β-carotene. Food Res Int. 2016;79:64–72. doi:10.1016/j.foodres.2015.11.025
  22. Xiao J, Li C, Huang Q. Kafirin Nanoparticle-Stabilized Pickering Emulsions as Oral Delivery Vehicles: Physicochemical Stability and in Vitro Digestion Profile. Journal of Agricultural and Food Chemistry. 2015 Nov 19;63(47):10263–70.
  23. Frelichowska J, Bolzinger MA, Pelletier J, Valour JP, Chevalier Y. Topical delivery of lipophilic drugs from o/w Pickering emulsions. International Journal of Pharmaceutics [Internet]. 2009 Apr 17;371(1):56–63. Available from: https://www.sciencedirect.com/science/article/pii/S0378517308008326
  24. Marto J, Duarte A, Simoes S, et al. Starch-based Pickering emulsions as platforms for topical antibiotic delivery: in vitro and in vivo studies. Polymers. 2019;11(1):108. doi:10.3390/polym11010108
  25. Sharkawy A, Barreiro MF, Rodrigues AE. New Pickering emulsions stabilized with chitosan/collagen peptides nanoparticles: synthesis, characterization and tracking of the nanoparticles after skin application. Colloid Surf A-Physicochem Eng Asp. 2021;616:126327.
  26. Wu XR, Zhang QA, Wang ZM, et al. Investigation of construction and characterization of carboxymethyl chitosan- sodium alginate nanoparticles to stabilize Pickering emulsion hydrogels for curcumin encapsulation and accelerating wound healing. Int J Biol Macromol. 2022;209:1837–1847. doi:10.1016/j.ijbiomac.2022.04.157
  27. Frelichowska J, Bolzinger MA, Valour JP, Mouaziz H, Pelletier J, Chevalier Y. Pickering w/o emulsions: Drug release and topical delivery. International Journal of Pharmaceutics. 2009 Feb;368(1-2):7–15.
  28. Leclercq L, Nardello-Rataj V. Pickering emulsions based on cyclodextrins: A smart solution for antifungal azole derivatives topical delivery. European Journal of Pharmaceutical Sciences. 2016 Jan;82:126–37.
  29. Marto J, Gouveia L, Jorge IM, Duarte A, Gonçalves LM, Silva SMC, et al. Starch-based Pickering emulsions for topical drug delivery: A QbD approach. Colloids and Surfaces B: Biointerfaces. 2015 Nov;135:183–92.
  30. Du YQ, Song TT, Wu J, et al. Engineering mannosylated Pickering emulsions for the targeted delivery of multicomponent vaccines. Biomaterials. 2022;280:121313. doi:10.1016/j.biomaterials.2021.121313
  31. Peng S, Cao FQ, Xia YF, et al. Particulate alum via Pickering emulsion for an enhanced COVID-19 vaccine adjuvant. Adv Mater. 2020;32 (40):2004210.
  32. Chen HB, Zhu HD, Hu JD, et al. Highly compressed assembly of deformable nanogels into nanoscale suprastructures and their application in nanomedicine. ACS Nano. 2011;5(4):2671–2680.
  33. Chen Y, Wang SB, Ma Q, et al. Utilizing endosomal capture for tumor therapy via membrane-lytic mechanism-based Pickering emulsion. J Control Release. 2023;354:523–537. doi:10.1016/j.jconrel.2023.01.035
  34. Deschamps F, Harris KR, Moine L, et al. Pickering-emulsion for liver trans-arterial chemo-embolization with oxaliplatin. Cardiovasc Interv Radiol. 2018;41(5):781–788.
  35. Li H, Qian K, Zhang HS, et al. Pickering gel emulsion of lipiodol stabilized by hairy nanogels for intra-artery embolization antitumor therapy. Chem Eng J. 2021;418:129534.
  36. Dieng SM, Anton N, Bouriat P, Thioune O, Sy PM, Massaddeq N, et al. Pickering nano-emulsions stabilized by solid lipid nanoparticles as a temperature sensitive drug delivery system. Soft Matter. 2019;15(40):8164–74.
  37. Zhang Y, Gu P, Jiao L, He J, Yu L, Liu Z, et al. Chinese yam polysaccharides PLGA-stabilized Pickering emulsion as an adjuvant system for PCV- 2 vaccine to enhance immune response. International Journal of Biological Macromolecules. 2022 Aug 10;219:1034–46.
  38. Guo Z, Guo C, Song Y, He C, He P, Wu F, et al. Antigens and adjuvants co-stabilized Pickering emulsions amplify immune responses of subunit vaccines. Journal of Controlled Release. 2025 Mar;379:177–90.
  39. Du Y, Jiali Lv, Hao Z, Li Z, Song T, Ge H, et al. Pickering emulsion-guided monomeric delivery of monophosphoryl lipid A for enhanced vaccination. Journal of Controlled Release. 2024 Aug 8;374:39–49.
  40. Jiao L, Liu Z, Zhang Y, Feng Z, Gu P, Huang Y, et al. Lentinan PLGA-stabilized pickering emulsion for the enhanced vaccination. International Journal of Pharmaceutics. 2021 Dec 4;611:121348–8.
  41. Li Z, Liu X, Xiao J, Jiang H, Ma L, Luo Y, et al. Ultrastable Iodinated Oil-Based Pickering Emulsion Enables Locoregional Sustained Codelivery of Hypoxia Inducible Factor-1 Inhibitor and Anticancer Drugs for Tumor Combination Chemotherapy. ACS biomaterials science & engineering. 2024 Mar 27;10(4):2270–81.
  42. Low LE, Tan LTH, Goh BH, Tey BT, Ong BH, Tang SY. Magnetic cellulose nanocrystal stabilized Pickering emulsions for enhanced bioactive release and human colon cancer therapy. International Journal of Biological Macromolecules. 2019 Apr;127:76–84.
  43. Lambros Tselikas, Thierry de Baere, Isoardo T, Sandrine Susini, Roux KSL, Mélanie Polrot, et al. Pickering emulsions with ethiodized oil and nanoparticles for slow release of intratumoral anti-CTLA4 immune checkpoint antibodies. Journal for ImmunoTherapy of Cancer. 2020 Jun 1;8(1):e000579–9.
  44. Jia L, Pang M, Fan M, Tan X, Wang Y, Huang M, et al. A pH-responsive Pickering Nanoemulsion for specified spatial delivery of Immune Checkpoint Inhibitor and Chemotherapy agent to Tumors. Theranostics. 2020;10(22):9956–69.
  45. Bao X, Wu J, Ma G. Sprayed Pickering emulsion with high antibacterial activity for wound healing. Progress in Natural Science: Materials International. 2020 Oct;30(5):669–76.
  46. Asfour MH, Elmotasem H, Mostafa DM, Salama AAA. Chitosan based Pickering emulsion as a promising approach for topical application of rutin in a solubilized form intended for wound healing: In vitro and in vivo study. International Journal of Pharmaceutics. 2017 Dec;534(1-2):325–38.
  47. Wu X, Zhang Q, Wang Z, Xu Y, Tao Q, Wang J, et al. Investigation of construction and characterization of carboxymethyl chitosan - sodium alginate nanoparticles to stabilize Pickering emulsion hydrogels for curcumin encapsulation and accelerating wound healing. International Journal of Biological Macromolecules. 2022 Jun;209:1837–47.
  48. Tong Q, Yi Z, Ma L, Tan Y, Liu D, Cao X, et al. Microenvironment-Responsive Antibacterial, Anti-Inflammatory, and Antioxidant Pickering Emulsion Stabilized by Curcumin-Loaded Tea Polyphenol Particles for Accelerating Infected Wound Healing. ACS Applied Materials & Interfaces. 2024 Aug 14;16(34):44467–84.

Reference

  1. Kale SN, Deore SL. Emulsion Micro Emulsion and Nano Emulsion: A Review. Systematic Reviews in Pharmacy [Internet]. 2016 Nov 19;8(1):39–47. Available from: https://www.sysrevpharm.org/fulltext/196-1568993217.pdf
  2. Wu J, Ma GH. Recent Studies of Pickering Emulsions: Particles Make the Difference. Small. 2016 Jun 23;12(34):4633–48.
  3. de Carvalho-Guimarães FB, Correa KL, de Souza TP, Rodríguez Amado JR, Ribeiro-Costa RM, Silva-Júnior JOC. A Review of Pickering Emulsions: Perspectives and Applications. Pharmaceuticals [Internet]. 2022 Nov 1;15(11):1413. Available from: https://www.mdpi.com/1424-8247/15/11/1413
  4. Wypych F, Alves R. Clay Minerals and Synthetic Analogous as Emulsifiers of Pickering Emulsions. Elsevier; 2022.
  5. Chevalier Y, Bolzinger MA. Emulsions stabilized with solid nanoparticles: Pickering emulsions. Colloids and Surfaces A: Physicochemical and Engineering Aspects. 2013 Dec; 439:23–34.
  6. Yang Y, Fang Z, Chen X, Zhang W, Xie Y, Chen Y, et al. An Overview of Pickering Emulsions: Solid-Particle Materials, Classification, Morphology, and Applications. Frontiers in Pharmacology. 2017 May 23;8.
  7. Albert C, Beladjine M, Tsapis N, Fattal E, Agnely F, Huang N. Pickering emulsions: Preparation processes, key parameters governing their properties and potential for pharmaceutical applications. Journal of Controlled Release. 2019 Sep;309:302–32.
  8. Wu J, Ma GH. Recent Studies of Pickering Emulsions: Particles Make the Difference. Small. 2016 Jun 23;12(34):4633–48.
  9. Chutia H, Mahanta CL. Properties of starch nanoparticle obtained by ultrasonication and high pressure homogenization for developing carotenoids-enriched powder and Pickering nanoemulsion. Innovative Food Science & Emerging Technologies. 2021 Dec;74:102822.
  10. Silva EK, Costa ALR, Gomes A, Bargas MA, Cunha RL, Meireles MAA. Coupling of high-intensity ultrasound and mechanical stirring for producing food emulsions at low-energy densities. Ultrasonics Sonochemistry [Internet]. 2018 Oct 1 [cited 2023 Apr 2];47:114–21. Available from: https://www.sciencedirect.com/science/article/pii/S1350417718306424?via%3Dihub
  11. Sun G, Qi F, Wu J, Ma G, Ngai T. Preparation of Uniform Particle-Stabilized Emulsions Using SPG Membrane Emulsification. Langmuir. 2014 Jun 9;30(24):7052–6.
  12. Opalski AS, Kaminski TS, Garstecki P. Droplet Microfluidics as a Tool for the Generation of Granular Matters and Functional Emulsions. KONA Powder and Particle Journal. 2019 Jan 10;36(0):50–71.
  13. Low LE, Siva SP, Ho YK, Chan ES, Tey BT. Recent advances of characterization techniques for the formation, physical properties and stability of Pickering emulsion. Advances in Colloid and Interface Science. 2020 Mar;277:102117.
  14. Ming Y, Xia Y, Ma G. Aggregating particles on the O/W interface: Tuning Pickering emulsion for the enhanced drug delivery systems. Aggregate. 2022 Feb 1;3(2).
  15. Dieng SM, Omran Z, Anton N, et al. Pickering nano-emulsions stabilized by Eudragit RL100 nanoparticles as oral drug delivery system for poorly soluble drugs. Colloid Surf B-Biointerfaces. 2020;191:111010 4.
  16. Torlopov MA, Vaseneva IN, Mikhaylov VI, Martakov IS, Moskalev AA, Koval LA, et al. Pickering emulsions stabilized by partially acetylated cellulose nanocrystals for oral administration: oils effect and in vivo toxicity. Cellulose. 2021 Jan 27;28(4):2365–85.
  17. Li Z, Liu W, Sun C, Wei X, Liu S, Jiang Y. Gastrointestinal pH-Sensitive Pickering Emulsions Stabilized by Zein Nanoparticles Coated with Bioactive Glycyrrhizic Acid for Improving Oral Bioaccessibility of Curcumin. ACS Applied Materials & Interfaces. 2023 Mar 8;
  18. Heba Elmotasem, Farag HK, Salama A. In vitro and in vivo evaluation of an oral sustained release hepatoprotective caffeine loaded w/o Pickering emulsion formula – Containing wheat germ oil and stabilized by magnesium oxide nanoparticles. International Journal of Pharmaceutics. 2018 Aug 25;547(1-2):83–96.
  19. Li XM, Li XH, Wu ZZ, et al. Chitosan hydrochloride/carboxymethyl starch complex nanogels stabilized Pickering emulsions for oral delivery of β-carotene: protection effect and in vitro digestion study. Food Chem. 2020;315:126288. doi:10.1016/j.foodchem.2020.126288
  20. Yi T, Liu C, Zhang J, Wang F, Wang J, Zhang J. A new drug nanocrystal self-stabilized Pickering emulsion for oral delivery of silybin. European Journal of Pharmaceutical Sciences. 2017 Jan 1;96:420–7.
  21. Shao Y, Tang CH. Gel-like pea protein Pickering emulsions at pH 3.0 as a potential intestine-targeted and sustained-release delivery system for β-carotene. Food Res Int. 2016;79:64–72. doi:10.1016/j.foodres.2015.11.025
  22. Xiao J, Li C, Huang Q. Kafirin Nanoparticle-Stabilized Pickering Emulsions as Oral Delivery Vehicles: Physicochemical Stability and in Vitro Digestion Profile. Journal of Agricultural and Food Chemistry. 2015 Nov 19;63(47):10263–70.
  23. Frelichowska J, Bolzinger MA, Pelletier J, Valour JP, Chevalier Y. Topical delivery of lipophilic drugs from o/w Pickering emulsions. International Journal of Pharmaceutics [Internet]. 2009 Apr 17;371(1):56–63. Available from: https://www.sciencedirect.com/science/article/pii/S0378517308008326
  24. Marto J, Duarte A, Simoes S, et al. Starch-based Pickering emulsions as platforms for topical antibiotic delivery: in vitro and in vivo studies. Polymers. 2019;11(1):108. doi:10.3390/polym11010108
  25. Sharkawy A, Barreiro MF, Rodrigues AE. New Pickering emulsions stabilized with chitosan/collagen peptides nanoparticles: synthesis, characterization and tracking of the nanoparticles after skin application. Colloid Surf A-Physicochem Eng Asp. 2021;616:126327.
  26. Wu XR, Zhang QA, Wang ZM, et al. Investigation of construction and characterization of carboxymethyl chitosan- sodium alginate nanoparticles to stabilize Pickering emulsion hydrogels for curcumin encapsulation and accelerating wound healing. Int J Biol Macromol. 2022;209:1837–1847. doi:10.1016/j.ijbiomac.2022.04.157
  27. Frelichowska J, Bolzinger MA, Valour JP, Mouaziz H, Pelletier J, Chevalier Y. Pickering w/o emulsions: Drug release and topical delivery. International Journal of Pharmaceutics. 2009 Feb;368(1-2):7–15.
  28. Leclercq L, Nardello-Rataj V. Pickering emulsions based on cyclodextrins: A smart solution for antifungal azole derivatives topical delivery. European Journal of Pharmaceutical Sciences. 2016 Jan;82:126–37.
  29. Marto J, Gouveia L, Jorge IM, Duarte A, Gonçalves LM, Silva SMC, et al. Starch-based Pickering emulsions for topical drug delivery: A QbD approach. Colloids and Surfaces B: Biointerfaces. 2015 Nov;135:183–92.
  30. Du YQ, Song TT, Wu J, et al. Engineering mannosylated Pickering emulsions for the targeted delivery of multicomponent vaccines. Biomaterials. 2022;280:121313. doi:10.1016/j.biomaterials.2021.121313
  31. Peng S, Cao FQ, Xia YF, et al. Particulate alum via Pickering emulsion for an enhanced COVID-19 vaccine adjuvant. Adv Mater. 2020;32 (40):2004210.
  32. Chen HB, Zhu HD, Hu JD, et al. Highly compressed assembly of deformable nanogels into nanoscale suprastructures and their application in nanomedicine. ACS Nano. 2011;5(4):2671–2680.
  33. Chen Y, Wang SB, Ma Q, et al. Utilizing endosomal capture for tumor therapy via membrane-lytic mechanism-based Pickering emulsion. J Control Release. 2023;354:523–537. doi:10.1016/j.jconrel.2023.01.035
  34. Deschamps F, Harris KR, Moine L, et al. Pickering-emulsion for liver trans-arterial chemo-embolization with oxaliplatin. Cardiovasc Interv Radiol. 2018;41(5):781–788.
  35. Li H, Qian K, Zhang HS, et al. Pickering gel emulsion of lipiodol stabilized by hairy nanogels for intra-artery embolization antitumor therapy. Chem Eng J. 2021;418:129534.
  36. Dieng SM, Anton N, Bouriat P, Thioune O, Sy PM, Massaddeq N, et al. Pickering nano-emulsions stabilized by solid lipid nanoparticles as a temperature sensitive drug delivery system. Soft Matter. 2019;15(40):8164–74.
  37. Zhang Y, Gu P, Jiao L, He J, Yu L, Liu Z, et al. Chinese yam polysaccharides PLGA-stabilized Pickering emulsion as an adjuvant system for PCV- 2 vaccine to enhance immune response. International Journal of Biological Macromolecules. 2022 Aug 10;219:1034–46.
  38. Guo Z, Guo C, Song Y, He C, He P, Wu F, et al. Antigens and adjuvants co-stabilized Pickering emulsions amplify immune responses of subunit vaccines. Journal of Controlled Release. 2025 Mar;379:177–90.
  39. Du Y, Jiali Lv, Hao Z, Li Z, Song T, Ge H, et al. Pickering emulsion-guided monomeric delivery of monophosphoryl lipid A for enhanced vaccination. Journal of Controlled Release. 2024 Aug 8;374:39–49.
  40. Jiao L, Liu Z, Zhang Y, Feng Z, Gu P, Huang Y, et al. Lentinan PLGA-stabilized pickering emulsion for the enhanced vaccination. International Journal of Pharmaceutics. 2021 Dec 4;611:121348–8.
  41. Li Z, Liu X, Xiao J, Jiang H, Ma L, Luo Y, et al. Ultrastable Iodinated Oil-Based Pickering Emulsion Enables Locoregional Sustained Codelivery of Hypoxia Inducible Factor-1 Inhibitor and Anticancer Drugs for Tumor Combination Chemotherapy. ACS biomaterials science & engineering. 2024 Mar 27;10(4):2270–81.
  42. Low LE, Tan LTH, Goh BH, Tey BT, Ong BH, Tang SY. Magnetic cellulose nanocrystal stabilized Pickering emulsions for enhanced bioactive release and human colon cancer therapy. International Journal of Biological Macromolecules. 2019 Apr;127:76–84.
  43. Lambros Tselikas, Thierry de Baere, Isoardo T, Sandrine Susini, Roux KSL, Mélanie Polrot, et al. Pickering emulsions with ethiodized oil and nanoparticles for slow release of intratumoral anti-CTLA4 immune checkpoint antibodies. Journal for ImmunoTherapy of Cancer. 2020 Jun 1;8(1):e000579–9.
  44. Jia L, Pang M, Fan M, Tan X, Wang Y, Huang M, et al. A pH-responsive Pickering Nanoemulsion for specified spatial delivery of Immune Checkpoint Inhibitor and Chemotherapy agent to Tumors. Theranostics. 2020;10(22):9956–69.
  45. Bao X, Wu J, Ma G. Sprayed Pickering emulsion with high antibacterial activity for wound healing. Progress in Natural Science: Materials International. 2020 Oct;30(5):669–76.
  46. Asfour MH, Elmotasem H, Mostafa DM, Salama AAA. Chitosan based Pickering emulsion as a promising approach for topical application of rutin in a solubilized form intended for wound healing: In vitro and in vivo study. International Journal of Pharmaceutics. 2017 Dec;534(1-2):325–38.
  47. Wu X, Zhang Q, Wang Z, Xu Y, Tao Q, Wang J, et al. Investigation of construction and characterization of carboxymethyl chitosan - sodium alginate nanoparticles to stabilize Pickering emulsion hydrogels for curcumin encapsulation and accelerating wound healing. International Journal of Biological Macromolecules. 2022 Jun;209:1837–47.
  48. Tong Q, Yi Z, Ma L, Tan Y, Liu D, Cao X, et al. Microenvironment-Responsive Antibacterial, Anti-Inflammatory, and Antioxidant Pickering Emulsion Stabilized by Curcumin-Loaded Tea Polyphenol Particles for Accelerating Infected Wound Healing. ACS Applied Materials & Interfaces. 2024 Aug 14;16(34):44467–84.

Neha Joshy
Corresponding author

Department of Pharmaceutics, College of Pharmaceutical Sciences, Government Medical College, Thiruvananthapuram, 695011.

Vinu Gopakumar Krishna
Co-author

Department of Pharmaceutics, College of Pharmaceutical Sciences, Government Medical College, Thiruvananthapuram, 695011

Prasanth M. S.
Co-author

Department of Pharmaceutics, College of Pharmaceutical Sciences, Government Medical College, Thiruvananthapuram, 695011

Neha Joshy*, Vinu Gopakumar Krishna, Prasanth M. S., A Detailed Review on Pharmaceutical Applications of Pickering Emulsion, Int. J. of Pharm. Sci., 2025, Vol 3, Issue 6, 1300-1314. https://doi.org/10.5281/zenodo.15610172

More related articles
Impact of Lipid Nanoparticle Size and Charge on Ly...
Ashvini Patmase, Mahesh Kurhe, Ankit Muley, Pratiksha Rajguru, Sa...
Review on a Thermodynamically Stable Nanolipoidal ...
Saiyedselimali, Pintukumar De, Abdus Samad, ...
A Review Article on Nanoparticle ...
Jatin Kumar, Ankush Uppal , Neeraj Bhandhari , ...
Comprehensive Review on Nanostructured Lipid Carriers...
Dr. Shaikh Nasheer, Limaye Akhilesh, Humnabade Shital, Anantwal Akshat, Babhulkar Akshay, Joshi Maha...
Characterization of Gastric Cancer (Stomach Cancer) its Situation and Nanotech/N...
Yash Srivastav , Anjani Mishra, Nutan Shrivastava, Madhaw Kumar, ...
Advancements In the Treatment of Diabetic Neuropathy: A Comprehensive Review of ...
Tahsin Attar , Rida Sayed , Sadiya Sabahat, Aamina Shaikh , Mantasha Sayyed , Rummanah Firdowsi, ...
Related Articles
Review on assessment of different analytical techniques for emulsion made for tr...
Pranav Shetake , Fayaka Attar, Sanika Jadhav, Dr. Priyanka Giakwad, ...
Green Synthesis of Silver Nanoparticles for Potential Therapeutical Applications...
Sine Bengia, Tanu Maibam, Reema Rongpi, Sarita Kotagori, Dr. Siva Shankar Prasad, ...
Nanoemulgel: A Promising Nanostructured Approach for Enhanced Topical Drug Deliv...
Kajal Shinde, Darshani Taral, Dhanashree Rajput, Anuja Khichade, Suman Hollikeri, Mayuri Patil, Aksh...
Microsponge: A Stable Microscopic Polymeric Delivery System ...
Anju Tomar, Aashish Singh, Dr. Narendra Mandoria, Kamlesh Dashora, ...
Impact of Lipid Nanoparticle Size and Charge on Lymph Node Transport and Distrib...
Ashvini Patmase, Mahesh Kurhe, Ankit Muley, Pratiksha Rajguru, Sahil Gadhave, Snehal Daud, ...
More related articles
Impact of Lipid Nanoparticle Size and Charge on Lymph Node Transport and Distrib...
Ashvini Patmase, Mahesh Kurhe, Ankit Muley, Pratiksha Rajguru, Sahil Gadhave, Snehal Daud, ...
A Review Article on Nanoparticle ...
Jatin Kumar, Ankush Uppal , Neeraj Bhandhari , ...
Impact of Lipid Nanoparticle Size and Charge on Lymph Node Transport and Distrib...
Ashvini Patmase, Mahesh Kurhe, Ankit Muley, Pratiksha Rajguru, Sahil Gadhave, Snehal Daud, ...
A Review Article on Nanoparticle ...
Jatin Kumar, Ankush Uppal , Neeraj Bhandhari , ...
